VIMBERG MINO
The Vimberg for most people. A generously proportioned full range floorstander with good weight, exceptional clarity and openess. Beautifully linear and neutral with remarkeable calmness and stability throught the range. The Mino is also forgivving and will slot into all sorts of systems and just seems to soudn so right and natural no matter what the material or partnering equipment.
“The extremely neutral and precise Mino plays in the uppermost echelons. Plasticity, dynamics and accuracy in exquisite material quality. Rather it is honest, and that’s what distinguishes the entire speaker. It embodies pure neutrality. The timing is almost unbelievable, as is the attention to detail and the pinpoint accuracy over the entire transmission range. Seamless dynamics, but also exquisite tonality should please the fans of classical music. In fact, this speaker is sensationally accurate, making it exciting and extremely fun!” T. Frantzen
| Velvetec (black or white) | Velvetec (colours range) | Piano Gloss Black or White |
| £32,000 | £33,300 | £33,300 |
Diamond Tweeter option on all models, +£9200
Copper/Brass faceplate option, £400
tweeter driver
Mino or Mino D?
You have the choice: the Mino comes with a 30 mm ceramic tweeter or optional with a 30 mm diamond tweeter. With our unique VIMBERG crossover technology the ceramic tweeter offers a clarity and openness in the high frequency level rarely heard. And for those who want to have the reference choice we do offer the even more exquisite 30 mm pure diamond tweeter option – and call it Mino D.
midrange driver
Ceramic midrange.
The Mino is being equipped with a 90 mm Accuton ceramic midrange woofer. Despite of its very hard and light diaphragm we managed to integrate this driver without any kind resonances at all and blend it perfectly into the tweeter and the woofers. Like no other.
WOOFER Driver
Aluminum sandwich woofer.
As woofers we do use three 168 mm Accuton woofers with 3D shaped honeycomb sandwich diaphragm made out of aluminum. These woofers do run in a perfectly calculated volume of air volume inside the Mino cabinet to reproduce an extreme fast and deep bass. Like no other.
CROSSOVER design
The architecture of perfect sound.
The VIMBERG Mino crossover is second to none in design and effort. Not only the parts and execution quality is exceptional, more important the topology was designed specifically for these drivers in this very construction. All this does correspond into superb off-axis performance, an ultra linear frequency response and incredible timing. Also the drivers are perfectly blended into each other without having any kind of resonance left. And the real kicker: we do manage all this avoiding impedance drops and low efficiency. Like no other.
ALUMINUM-HDF HYBRID
Best from both worlds.
The whole high-midrange unit and all woofers of the VIMBERG Mino are being installed into an aluminum front plate and internal aluminum mountings. While being as material for a speaker cabinet a compromised choice since its resonance behaviour, in this case aluminum reinforces the construction of the Mino. In combination with the resonance absorbing waterproof HDF fibre laminate the unit gives extremely tight hold to the drivers for utmost precision.
ISOLATION STAND
Stability & Isolation.
The VIMBERG Mino comes with a massive footer, which we do mill out of one block aluminum, a complex shape with many different angles. This stand then is connected to a 5-part isolation device with a Teflon-glider inlay to have the very best isolation and height adjustment to different grounds such as hardwood floors, tiles or even carpet.
BEST CONNECTION
Best signals are welcome.
Each VIMBERG loudspeaker is using original Argento binding posts. Being moulded out of a fibre-reinforced polymer it avoids any kind of magnetically interference with the conductor itself. Internally each VIMBERG speaker is being wired with a true highend coaxial cable.
-
- 3-way fullrange loudspeaker
- VIMBERG™ MRD-cabinet made out of waterproof high density fiberlaminate and reinfocring aluminum elements for all drivers
- 1 x 30 mm Accuton™ Cell ceramic tweeter
- 1 x 90 mm Accuton™ Cell ceramic midrange woofer
- 3 x 168 mm Accuton™ Cell woofer, long excursion design with 3D shaped honeycomb sandwich diaphragm
- optional: 30mm Accuton™ Cell diamond tweeter (Mino D), also upgradeable anytime later
- highend Mogami™ speaker cable wiring inside, Argento™ binding posts
- highend crossover with VIMBERG™ monopulse technology: linear frequency response with optimized impulse response
- exclusive use of Mundorf™ & Duelund™ components
- dual-Tune bassreflex port design for lowest port noise and selectable F3
- decoupling height adjustable isolation gliders and 3D-shaped installation triggers for optimized setup and placement to every floor
- exclusive VIMBERG™ VELVETEC: Summit White, Jet Black, Slate Grey, Sonoma Orange, Amethyst and other colors on request
- optional on request: VIMBERG™ real piano lacquer: summit white or jet black
- nominal impedance: 4 ohm (lowest point: 3.8 ohm at 100Hz)
- efficiency at 2.83V/1m/1KHz: 89dB
- weight without packagaing: 2 x 72 Kg (2 x 159 lbs.)
- weight incl. packaging: 2 x 83 Kg (2 x 183 lbs.)
- weight incl. optional ATA flightcases: 2 x 108 Kg (2 x 238 lbs.)
- shipment dimensions: W 40cm x L 155 cm x H 60 cm
